SHANTUI BULLDOZER SD22

FOB Reference Price Get Latest Price
US $70,000-150,000/Set

Brand: Shantui

ENGINE POWER: WITH 175KW/1800RPM, THIS ENGINE CONFORMS TO CHINA-III EMISSION REGULATION

OVERALL WEIGHT: 23,450KG (STANDARD)

ENGINE MODEL: NTA855-C280

Download Catalog

Overview

Quick Details

Condition: New

Warranty: 6 months

Supply Ability: Supply Ability:1500 Unit/Units per Month

Place of Origin: Shandong, China

Name: Weichai engine Ass’y WD615 for shantui dzoer SD16

Product Description

Parameter name	SD22 (Standard version)	SD22C (Coal version)	SD22W (Rock version)	SD22F (Forestry version)	SD22D (Desert version)	SD22E (Extended version)	SD22R (Environmental sanitation version)	SD22S (Wetland version)
Performance parameters
Operating weight (Kg)	23450	24000	23600	24700	24600	24600	26000	25700
Ground pressure (kPa)	66	57.5	66	64	56	66	36	35.2
Engine
Engine model	WP12/QSNT-C235	WP12/QSNT-C235	QSNT-C235	QSNT-C235	QSNT-C235	QSNT-C235	WP12/QSNT-C235	WP12/QSNT-C235
Rated power/rated speed (kW/rpm)	175/1800	175/1800	175/1800	175/1800	175/1800	175/1800	175/1800	175/1800
Overall dimensions
Overall dimensions of machine (mm)	549537253402	582042003402	549537253402	549537253402	549537253402	549537253402	629043653745	629043653402
Driving performance
Forward speed (km/h)	F1：0-3.6 F2:0-6.5 F3:0-11.2	F1：0-3.6 F2:0-6.5 F3:0-11.2	F1：0-3.6 F2:0-6.5 F3:0-11.2	F1：0-3.6 F2:0-6.5 F3:0-11.2	F1：0-3.6 F2:0-6.5 F3:0-11.2	F1：0-3.6 F2:0-6.5 F3:0-11.2	F1：0-3.6 F2:0-6.5 F3:0-11.2	F1：0-3.6 F2:0-6.5 F3:0-11.2
Reversing speed (km/h)	R1:0-4.3 R2:0-7.7 R3:0-13.2	R1:0-4.3 R2:0-7.7 R3:0-13.2	R1:0-4.3 R2:0-7.7 R3:0-13.2	R1:0-4.3 R2:0-7.7 R3:0-13.2	R1:0-4.3 R2:0-7.7 R3:0-13.2	R1:0-4.3 R2:0-7.7 R3:0-13.2	R1:0-4.3 R2:0-7.7 R3:0-13.2	R1:0-4.3 R2:0-7.7 R3:0-13.2
Chassis System
Center distance of track (mm)	2000	2000	2000	2000	2000	2000	2250	2250
Width of track shoes (mm)	560/610/660	660	560/610/660	610/660	660	560/610/660	910	910
Ground length（mm)	2730	2730	2730	2730	3050	3050	3480	3480
Tank capacity
Fuel tank (L)	450	450	450	450	450	450	450	450
Working device
Blade type	Straight tilting blade , Angle Blade, U-shaped Blade and Semi-U blade	Coal blade	Rock straight tilting blade, rock angle blade, rock U-blade, and rock semi-U blade	Straight tilting blade , Angle Blade, U-shaped Blade and Semi-U blade	Straight tilting blade , Angle Blade, U-shaped Blade and Semi-U blade	Straight tilting blade , Angle Blade, U-shaped Blade and Semi-U blade	Sanitation blade	Straight tilting blade
Digging depth (mm)	540	538	540	540	540	540	550	550
Ripper type	Single-shank three-shank	Single-shank three-shank	Single-shank three-shank	Single-shank three-shank	Single-shank three-shank	Single-shank three-shank	–	–
Ripping depth (mm)	695 (Single-shank) and 666 (Three-shank)	695 (Single-shank) and 666 (Three-shank)	695 (Single-shank) and 666 (Three-shank)	695 (Single-shank) and 666 (Three-shank)	695 (Single-shank) and 666 (Three-shank)	695 (Single-shank) and 666 (Three-shank)	–	–
